125mm Thermoplastic Rubber Castors with Brake
SKU
125-3360-MGR/SWB
This 125 mm swivel braked castor with thermoplastic rubber wheel is engineered for applications where smooth movement and secure braking are... Read Full Description
In stock
£15.96
£13.30
- Price
- 1 + £15.96 £13.30
CAD Request
Frequently bought together
Alternative Products
Description
This 125 mm swivel braked castor with thermoplastic rubber wheel is engineered for applications where smooth movement and secure braking are essential. The swivel action allows easy directional changes, while the foot-operated brake locks both the wheel and swivel head when stationary, helping to stabilise heavier mobile equipment.
With a load capacity of 150 kg per castor, this model is ideal for medium-duty industrial and commercial use, including trolleys, mobile workstations, display units and handling equipment. The roller bearing ensures smooth rolling under load and reduces friction and wear during frequent use. With a maximum combined load capacity of 450 kg across four castors, it provides dependable performance for larger and heavier platforms.
The thermoplastic rubber wheel delivers quiet operation, effective shock absorption and excellent floor protection with non-marking tread. Featuring a tread hardness of 88 Shore A and an operating temperature range of –20°C to +60°C, this castor performs reliably across a range of indoor environments. The larger 125 mm wheel diameter enhances rolling efficiency and obstacle clearance, while the 155 mm total castor height maintains stability without significantly increasing overall equipment height. A robust top plate fixing ensures secure and straightforward installation.
Key Features
-
Swivel castor with brake – Easy manoeuvrability with secure locking
-
Top plate fixing – Secure and stable mounting
-
125 mm wheel diameter – Good rolling performance and obstacle clearance
-
150 kg load capacity per castor – Suitable for medium-duty applications
-
Grey thermoplastic rubber wheel – Quiet, non-marking and floor-friendly
-
Rubber on polypropylene construction – Durable and shock absorbing
-
Roller bearing – Smooth rolling under load
-
Operating temperature range: –20°C to +60°C
Specifications
-
Castor Type: Swivel Braked, Top Plate
-
Bearing Type: Roller
-
Load Capacity: 150 kg per castor
-
Max Load Capacity of 4 Castors: 450 kg
-
Wheel Diameter: 125 mm
-
Tread Width: 40 mm
-
Wheel Material: Rubber on Polypropylene
-
Wheel Colour: Grey
-
Tread Hardness: 88 Shore A
-
Temperature Range: –20°C to +60°C
-
Total Castor Height: 155 mm
-
Swivel Radius: 103 mm
-
Plate Length: 105 mm
-
Plate Width: 85 mm
-
Plate Hole Centres: 80 × 60 mm
-
Plate Hole Diameter: 8 mm
Applications
Commonly used for:
-
Medium-duty industrial and workshop trolleys
-
Mobile workstations and benches
-
Larger handling carts
-
Equipment fixtures and bases
-
Indoor environments requiring quiet operation and secure braking
Why Choose Ross Handling
Ross Handling supplies a carefully selected range of castors and wheels chosen for strength, durability and reliable performance. Products are sourced from trusted manufacturers to meet the practical demands of commercial and industrial use.
This 125 mm swivel braked castor with thermoplastic rubber wheel delivers smooth manoeuvrability, dependable braking and robust load support — making it a solid choice for a wide range of medium-duty applications.
Technical Details
 |
Top Plate Castors |
|---|---|
|
|
Roller |
|
|
150 |
|
|
TSZ7 MGR 125/30 P2 BP |
|
|
125-3360-MGR-SWB.pdf |
|
|
40 |
|
|
-20 min to +60 max |
|
|
88 shore A |
|
|
450 |
|
|
105 |
|
|
85 |
|
|
80 |
|
|
60 |
|
|
8 |
|
|
103 |
|
|
155 |
|
|
Grey |
|
|
125 |
|
|
Rubber on Polypropylene |
