160mm Bolt Hole Industrial Castor with Nylon Wheel
SKU
160-4000-NYB
This 160mm swivel bolt hole castor is designed for heavy-duty industrial applications where high load capacity and smooth manoeuvrability are... Read Full Description
In stock
£25.62
£21.35
- Price
- 1 + £25.62 £21.35
CAD Request
Frequently bought together
Alternative Products
Description
This 160mm swivel bolt hole castor is designed for heavy-duty industrial applications where high load capacity and smooth manoeuvrability are essential. With a load capacity of up to 200 kg per castor, it is ideal for larger trolleys, mobile machinery and equipment requiring controlled, reliable movement.
Fitted with a durable nylon wheel and roller bearing, this castor provides smoother rolling performance under heavier loads while maintaining excellent resistance to wear, impact and chemicals. It performs reliably across a wide temperature range from -40°C to +80°C, making it suitable for demanding environments. The swivel head ensures precise directional control, while the bolt hole fixing allows for quick and secure installation.
Key Features & Specifications
General
-
Castor Type: Swivel Bolt Hole Castor
-
Bearing Type: Roller
-
Maximum Load Capacity (per castor): 200 kg
-
Maximum Load Capacity (4 castors): 600 kg
-
Colour: White
Wheel Details
-
Wheel Diameter: 160 mm
-
Tread Width: 40 mm
-
Wheel Material: Nylon
-
Tread Hardness: D75
Dimensions & Mounting
-
Total Castor Height: 195 mm
-
Swivel Radius: 135 mm
-
Bolt Hole Diameter: 12 mm
Performance
-
Temperature Range: -40°C to +80°C
-
Smooth rolling under load thanks to roller bearing design
Typical Applications
-
Heavy-duty industrial trolleys
-
Mobile machinery and equipment
-
Warehouse and factory handling systems
-
Commercial and industrial transport applications
Why Choose Ross Handling
Ross Handling supplies robust castor solutions engineered for strength, reliability and long-term performance. This 160mm nylon swivel bolt hole castor combines high load capacity with smooth rolling performance, making it a dependable choice for demanding industrial environments.
Technical Details
 |
Bolt Hole Castors |
|---|---|
|
|
Roller |
|
|
200 |
|
|
TSZ7 NSR 160/40 FR-12 |
|
|
160-4000-NYB.pdf |
|
|
40 |
|
|
-40 min to + 80 max |
|
|
12 |
|
|
D75 |
|
|
600 |
|
|
135 |
|
|
195 |
|
|
White |
|
|
160 |
|
|
Nylon |
