200mm Heavy Duty Leading Brake Castors with Polyurethane Castor Wheel
SKU
200-5000-PAL/FR
This 200 mm heavy-duty swivel castor with leading brake delivers high load support,
In Stock
£83.92
£69.93
CAD Request
Frequently bought together
Alternative Products
Description
This 200 mm heavy-duty swivel castor with leading brake delivers high load support, controlled manoeuvrability and enhanced braking performance for demanding industrial applications. The leading brake engages when the wheel rolls forward to help moderate movement and stabilise heavy equipment, especially useful on slight gradients or busy workshop floors.
With an 800 kg load capacity per castor, it’s ideal for industrial trolleys, equipment bases, material-handling platforms and production carts that operate under significant loads. The ball journal swivel bearing provides smooth, dependable rotation under load, supporting reliable performance and long service life in tough environments.
The polyurethane on aluminium wheel combines a lightweight aluminium core with a durable polyurethane tread, offering excellent load support, vibration absorption and floor protection. The 50 mm tread width and 92 Shore A hardness deliver a resilient running surface that balances traction, wear resistance and quieter rolling. Designed for use across a temperature range of –20 °C to +60 °C, this castor performs reliably in a wide variety of indoor industrial settings.
A large top plate fixing (140 × 110 mm) with 105 × 80/75 mm hole centres and 10 mm hole diameter ensures secure mounting and effective load distribution for heavy-duty installations requiring both controlled movement and braking support.
Key Features
-
Heavy-duty swivel castor with leading brake – Enhanced control when moving forward
-
800 kg load capacity per castor – Strong industrial performance
-
Polyurethane on aluminium wheel – Durability, floor protection and quiet running
-
200 mm wheel diameter – Efficient rolling under heavy load
-
50 mm tread width – Excellent stability and surface contact
-
Ball journal swivel bearing – Smooth, low-resistance rotation
-
Large top plate fixing – Secure mount for heavy equipment
-
Operating temperature range –20 °C to +60 °C
Specifications
-
Castor Type: Swivel with Leading Brake, Top Plate
-
Load Capacity: 800 kg per castor
-
Max Load Capacity of 4 Castors: 2400 kg
-
Wheel Diameter: 200 mm
-
Tread Width: 50 mm
-
Wheel Material: Polyurethane on Aluminium
-
Wheel Colour: Yellow
-
Tread Hardness: 92 Shore A
-
Bearing Type: Ball Journal (Swivel Head)
-
Temperature Range: –20 °C to +60 °C
-
Total Castor Height: 240 mm
-
Swivel Radius: 180 mm
-
Plate Length: 140 mm
-
Plate Width: 110 mm
-
Plate Hole Centres: 105 × 80/75 mm
-
Plate Hole Diameter: 10 mm
Applications
Commonly used for:
-
Heavy-duty industrial trolleys and carts
-
Machinery bases and support frames
-
Material handling and warehouse systems
-
Manufacturing and assembly equipment
-
Applications requiring controlled forward braking with high load support
Why Choose Ross Handling
Ross Handling supplies a carefully selected range of heavy-duty castors engineered for strength, durability and dependable performance in industrial environments. Products are chosen to meet the practical needs of commercial, manufacturing and logistics users.
This 200 mm heavy-duty swivel castor with leading brake and polyurethane on aluminium wheel delivers excellent load capacity, smooth rolling and enhanced braking control, making it a dependable choice for demanding handling applications.
Technical Details
 |
Top Plate Castors |
|---|---|
|
|
Ball Journal |
|
|
800 |
|
|
200-5000-PAL-FR.pdf |
|
|
50 |
|
|
-20 min to +60 max |
|
|
92 shore A |
|
|
2400 |
|
|
140 |
|
|
110 |
|
|
105 |
|
|
80/75 |
|
|
10 |
|
|
180 |
|
|
240 |
|
|
Yellow |
|
|
200 |
|
|
Polyurethane on Aluminium |
