Fixed Castors with 8" Ergonomic Wheel
SKU
CCAPEX-8R
These 8″ (approx. 203 mm) fixed top plate castors with ergonomic wheels are designed for robust,... Read Full Description
In stock
£83.33
£69.44
- Price
- 1 + £83.33 £69.44
CAD Request
Frequently bought together
Alternative Products
Description
These 8″ (approx. 203 mm) fixed top plate castors with ergonomic wheels are designed for robust, straight-line movement under heavy loads in demanding industrial environments. With a load capacity of up to 544 kg per castor, they are ideal for heavy trolleys, equipment platforms, production line carts and mobile systems that require stable, dependable performance without steering.
Fitted with large 8″ ergonomic polyurethane wheels, these castors deliver excellent shock absorption, low rolling resistance and enhanced protection for floor surfaces—even on rough or debris-covered floors. The wheels perform reliably across a wide temperature range from –20 °C to +80 °C. The precision ball journal bearings ensure smooth, controlled rolling under load, while the fixed design provides solid directional stability for straight-line handling.
Key Features & Specifications
General
-
Castor Type: Fixed Top Plate Castor
-
Bearing Type: Ball Journal
-
Maximum Load Capacity (per castor): 544 kg
-
Maximum Load Capacity (4 castors): 1632 kg
-
Colour: Orange
Wheel Details
-
Wheel Diameter: 8″ (203 mm)
-
Tread Width: 50 mm
-
Wheel Material: Ergonomic Polyurethane
-
Tread Hardness: 87 Shore A
-
Temperature Range: –20 °C to +80 °C
Mounting & Dimensions
-
Plate Length: 114 mm
-
Plate Width: 102 mm
-
Hole Centres: 92/75 mm × 75/67 mm
-
Plate Hole Diameter: 10 mm
-
Total Castor Height: 241 mm
Performance
-
Smooth rolling with enhanced shock absorption
-
Ball journal bearing for dependable movement
-
Fixed design for strong, straight-line load support
Typical Applications
-
Heavy-duty industrial trolleys and equipment
-
Factory and warehouse handling
-
Production and processing environments
-
Logistics and storage systems
Why Choose Ross Handling
Ross Handling supplies engineered castor solutions built for durability, performance and long service life. These 8″ fixed ergonomic polyurethane castors offer exceptional load capacity, smooth movement and reliable performance — making them a practical choice for heavy-duty industrial handling and transport applications.
Technical Details
 |
Top Plate Castors |
|---|---|
|
|
Ball Journal |
|
|
544 |
|
|
50 |
|
|
-20 min to +80 max |
|
|
87A |
|
|
1632 |
|
|
114 |
|
|
102 |
|
|
92/75 |
|
|
75/67 |
|
|
10 |
|
|
241 |
|
|
Orange |
|
|
8" |
|
|
Ergonomic Polyurethane |
