200mm Heavy Duty Fixed Castors Polyurethane Wheel 800kg
SKU
200-5050-SUB
This 200 mm heavy-duty fixed castor with a polyurethane on cast iron wheel is engineered for... Read Full Description
In stock
£75.50
£62.92
- Price
- 1 + £75.50 £62.92
CAD Request
Frequently bought together
Alternative Products
Description
This 200 mm heavy-duty fixed castor with a polyurethane on cast iron wheel is engineered for straight-line movement in very demanding industrial applications where high load support, robust wheel performance and stable directional control are essential. The fixed housing provides reliable tracking, making this model ideal for equipment that travels in a set direction under significant loads.
With an 800 kg load capacity per castor, this model offers exceptional load support for heavy industrial trolleys, machinery bases, material handling platforms and production equipment. The ball journal bearing provides smooth, dependable rolling performance under load, contributing to long service life in tough industrial environments.
The polyurethane on cast iron wheel combines a solid cast iron core with a high-performance polyurethane tread, delivering excellent load support, high abrasion resistance and smooth rolling characteristics. The 50 mm tread width and A92 Shore hardness create a tough, resilient running surface that balances durability, floor protection and load distribution. Designed for use within a temperature range of –40°C to +60°C, this castor performs reliably across a wide range of indoor industrial settings.
A large top plate fixing (140 × 110 mm) with 105 × 80/75 mm hole centres ensures secure mounting and effective load distribution for heavy-duty installations.
Key Features
-
Heavy-duty fixed castor – Stable straight-line movement under load
-
800 kg load capacity per castor – Exceptional support for industrial use
-
Polyurethane on cast iron wheel – Durable and high abrasion resistance
-
200 mm wheel diameter – Efficient rolling under heavy loads
-
50 mm tread width – Enhanced stability and floor contact
-
Ball journal bearing – Reliable, smooth rotation
-
Large top plate fixing – Secure mounting for heavy equipment
-
Operating temperature range –40°C to +60°C
Specifications
-
Castor Type: Fixed, Top Plate
-
Load Capacity: 800 kg per castor
-
Max Load Capacity of 4 Castors: 2400 kg
-
Wheel Diameter: 200 mm
-
Tread Width: 50 mm
-
Wheel Material: Polyurethane on Cast Iron
-
Wheel Colour: Yellow
-
Tread Hardness: A92 Shore
-
Bearing Type: Ball Journal
-
Temperature Range: –40°C to +60°C
-
Total Castor Height: 240 mm
-
Plate Length: 140 mm
-
Plate Width: 110 mm
-
Plate Hole Centres: 105 × 80/75 mm
-
Plate Hole Diameter: 10 mm
Applications
Commonly used for:
-
Heavy-duty industrial trolleys and platforms
-
Machinery bases and equipment frames
-
Material handling systems and warehouse carts
-
Manufacturing and assembly equipment
-
Applications requiring stable fixed movement under very high loads
Why Choose Ross Handling
Ross Handling supplies a carefully selected range of heavy-duty castors engineered for strength, durability and dependable performance in industrial environments. Products are chosen to meet the practical demands of commercial, manufacturing and logistics users.
This 200 mm heavy-duty fixed castor with polyurethane on cast iron wheel delivers excellent load capacity, stable movement and robust construction, making it a dependable choice for demanding material handling applications.
Technical Details
 |
Top Plate Castors |
|---|---|
|
|
Ball Journal |
|
|
800 |
|
|
200-5050-SUB_1.pdf |
|
|
50 |
|
|
-40 min to + 60 max |
|
|
A92 |
|
|
2400 |
|
|
140 |
|
|
110 |
|
|
105 |
|
|
80/75 |
|
|
10 |
|
|
240 |
|
|
Yellow |
|
|
200 |
|
|
Polyurethane on Cast Iron |
