CC Apex Fixed Ergonomic Castor Wheel 5"
SKU
CCAPEX-5R
This 5″ (approximately 127 mm) fixed Apex ergonomic castor is designed for smooth, controlled... Read Full Description
In stock
£45.71
£38.09
- Price
- 1 + £45.71 £38.09
CAD Request
Frequently bought together
Alternative Products
Description
This 5″ (approximately 127 mm) fixed Apex ergonomic castor is designed for smooth, controlled straight-line movement in industrial and commercial settings where durability and load support matter. With a load capacity of up to 362 kg per castor, it’s ideal for heavy trolleys, equipment carts and mobile platforms that demand robust performance.
Fitted with an ergonomic polyurethane wheel, this castor delivers excellent shock absorption, low rolling resistance and strong floor protection, making it suitable for hard-wearing environments. Its performance remains reliable across a wide temperature range from –20 °C to +80 °C, while the ball journal bearing provides smooth rolling and dependable manoeuvrability even under load.
Key Features & Specifications
General
-
Castor Type: Fixed Top Plate Castor
-
Bearing Type: Ball Journal
-
Maximum Load Capacity (per castor): 362 kg
-
Maximum Load Capacity (4 castors): 1086 kg
-
Colour: Orange
Wheel Details
-
Wheel Diameter: 5″ (127 mm)
-
Tread Width: 50 mm
-
Wheel Material: Ergonomic Polyurethane
-
Tread Hardness: 87 Shore A
-
Temperature Range: –20 °C to +80 °C
Mounting & Dimensions
-
Plate Length: 114 mm
-
Plate Width: 102 mm
-
Hole Centres: 92/75 mm × 75/67 mm
-
Plate Hole Diameter: 10 mm
-
Total Castor Height: 165 mm
Performance
-
Smooth, low-resistance rolling
-
Excellent shock absorption and floor protection
-
Stable fixed design for direct load movement
Typical Applications
-
Industrial trolleys and carts
-
Equipment transport and handling
-
Warehouse and factory operations
-
Material handling systems
Why Choose Ross Handling
Ross Handling supplies engineered castor solutions built for strength, performance and long service life. This 5″ fixed Apex ergonomic castor with polyurethane wheel and ball bearings offers dependable movement and robust load support — making it a practical choice for heavy-duty industrial and commercial handling tasks.
Technical Details
 |
Top Plate Castors |
|---|---|
|
|
Ball Journal |
|
|
362 |
|
|
50 |
|
|
-20 min to +80 max |
|
|
87A |
|
|
1086 |
|
|
114 |
|
|
102 |
|
|
92/75 |
|
|
75/67 |
|
|
10 |
|
|
165 |
|
|
Orange |
|
|
5" |
|
|
Ergonomic Polyurethane |
