100mm Fixed Non Marking Blue Rubber Castors 160kg Capacity
SKU
100-3368-RNB
This 100 mm fixed castor with blue rubber wheel is designed for applications requiring stable, straight-line movement combined with reliable load... Read Full Description
In stock
£9.58
£7.98
- Price
- 1 + £9.58 £7.98
CAD Request
Frequently bought together
Alternative Products
Description
This 100 mm fixed castor with blue rubber wheel is designed for applications requiring stable, straight-line movement combined with reliable load performance. The fixed housing ensures controlled tracking in one direction, making it ideal for trolleys, mobile equipment and guided systems where directional stability is required.
With a load capacity of 160 kg per castor, this model is well suited to medium- and heavy-duty industrial and commercial environments. The roller bearing construction delivers smooth rolling under load while reducing rolling resistance and wear during continuous use.
The rubber on polypropylene wheel provides effective shock absorption, quiet operation and good floor protection. With a tread hardness of A64 and a temperature operating range of –20°C to +80°C, this castor performs reliably across a wide range of indoor and light industrial conditions. The 100 mm wheel diameter improves rolling efficiency and obstacle clearance, while the 128 mm total castor height maintains stability without excessively increasing overall equipment height. A strong top plate fixing ensures secure and straightforward installation.
Key Features
-
Fixed castor – Stable, straight-line movement
-
Top plate fixing – Secure and reliable mounting
-
100 mm wheel diameter – Improved rolling performance and clearance
-
160 kg load capacity per castor – Suitable for medium to heavy duty use
-
Blue rubber wheel – Quiet operation and floor protection
-
Rubber on polypropylene construction – Durable and shock absorbing
-
Roller bearing – Smooth rolling under load
-
Wide operating temperature range – –20°C to +80°C
Specifications
-
Castor Type: Fixed, Top Plate
-
Bearing Type: Roller
-
Load Capacity: 160 kg per castor
-
Max Load Capacity of 4 Castors: 480 kg
-
Wheel Diameter: 100 mm
-
Tread Width: 29 mm
-
Wheel Material: Rubber on Polypropylene
-
Wheel Colour: Blue
-
Tread Hardness: A64
-
Temperature Range: –20°C to +80°C
-
Total Castor Height: 128 mm
-
Plate Length: 101 mm
-
Plate Width: 85 mm
-
Plate Hole Centres: 80 / 77 × 60 mm
-
Plate Hole Diameter: 8 mm
Applications
Commonly used for:
-
Industrial and workshop trolleys
-
Conveyor and guided systems
-
Mobile workbenches and equipment
-
Material handling units
-
Warehousing and production environments requiring straight-line movement
Why Choose Ross Handling
Ross Handling supplies a carefully selected range of castors and wheels chosen for strength, durability and dependable performance. Products are sourced from trusted manufacturers to meet the practical demands of commercial and industrial applications.
This 100 mm fixed castor with blue rubber wheel offers stable movement, smooth rolling and reliable load handling, making it a dependable choice for controlled, linear motion in industrial environments.
Technical Details
 |
Top Plate Castors |
|---|---|
|
|
Roller |
|
|
160 |
|
|
TSZ7 NER 100/35 P2 FA 5017 |
|
|
100-3368-RNB_2.pdf |
|
|
29 |
|
|
-20 min to +80 max |
|
|
A64 |
|
|
480 |
|
|
101 |
|
|
85 |
|
|
80/77 |
|
|
60 |
|
|
8 |
|
|
128 |
|
|
Blue |
|
|
100 |
|
|
Rubber on Polypropylene |
