160mm Thermoplastic Rubber Castors with Brake
SKU
160-3360-MGR/SWB
This 160 mm swivel braked castor with thermoplastic rubber wheel is engineered for heavier-duty applications where smooth manoeuvrability and... Read Full Description
In stock
£31.94
£26.62
- Price
- 1 + £31.94 £26.62
CAD Request
Frequently bought together
Alternative Products
Description
This 160 mm swivel braked castor with thermoplastic rubber wheel is engineered for heavier-duty applications where smooth manoeuvrability and secure braking are essential. The swivel action allows easy directional changes, while the integrated brake locks both wheel and swivel to keep equipment reliably in place when stationary.
With a load capacity of 200 kg per castor, this model is ideal for industrial trolleys, mobile workstations, handling carts and equipment platforms in commercial or light industrial environments. The roller bearing ensures smooth, low-resistance movement under load, helping to reduce wear during frequent use. A maximum combined load capacity of 600 kg across four castors provides dependable support for larger and heavier equipment.
The thermoplastic rubber wheel delivers quiet operation, effective shock absorption and excellent floor protection with a non-marking tread. Featuring a tread hardness of 88 Shore A and an operating temperature range of –20 °C to +60 °C, this castor performs reliably in a wide range of indoor environments. The 160 mm wheel diameter improves rolling efficiency and obstacle clearance, while the 200 mm total castor height helps maintain stability without unduly increasing overall equipment height. A robust top plate fixing ensures secure and straightforward installation.
Key Features
-
Swivel castor with brake – Smooth turning action with positive locking
-
Top plate fixing – Sturdy and stable mounting
-
160 mm wheel diameter – Excellent rolling performance and obstacle clearance
-
200 kg load capacity per castor – Robust performance for higher-load applications
-
Grey thermoplastic rubber wheel – Quiet, non-marking and floor-friendly
-
Rubber on polypropylene construction – Durable and shock absorbing
-
Roller bearing – Smooth rolling under load
-
Operating temperature range: –20 °C to +60 °C
Specifications
-
Castor Type: Swivel Braked, Top Plate
-
Bearing Type: Roller
-
Load Capacity: 200 kg per castor
-
Max Load Capacity of 4 Castors: 600 kg
-
Wheel Diameter: 160 mm
-
Tread Width: 40 mm
-
Wheel Material: Rubber on Polypropylene
-
Wheel Colour: Grey
-
Tread Hardness: 88 Shore A
-
Temperature Range: –20 °C to +60 °C
-
Total Castor Height: 200 mm
-
Swivel Radius: 135 mm
-
Plate Length: 140 mm
-
Plate Width: 110 mm
-
Plate Hole Centres: 105 × 80 / 75 mm
-
Plate Hole Diameter: 10 mm
Applications
Commonly used for:
-
Medium- to heavy-duty industrial trolleys
-
Mobile workstations and production carts
-
Larger handling platforms and equipment
-
Material handling units
-
Indoor environments requiring secure braking and controlled mobility
Why Choose Ross Handling
Ross Handling supplies a carefully selected range of industrial castors and wheels chosen for strength, durability and dependable performance. Products are sourced from trusted manufacturers to meet the practical demands of commercial and light industrial use.
This 160 mm swivel braked castor with thermoplastic rubber wheel delivers smooth manoeuvrability, robust load capacity and reliable braking — making it an excellent choice for demanding applications.
Technical Details
 |
Top Plate Castors |
|---|---|
|
|
Roller |
|
|
200 |
|
|
TSZ7 MGR 160/40 P3 BP |
|
|
160-3360-MGR-SWB.pdf |
|
|
40 |
|
|
-20 min to +60 max |
|
|
88 shore A |
|
|
600 |
|
|
140 |
|
|
110 |
|
|
105 |
|
|
80/75 |
|
|
10 |
|
|
135 |
|
|
200 |
|
|
Grey |
|
|
160 |
|
|
Rubber on Polypropylene |
