200mm Apex Heavy Duty Leading Brake Castors with Polyurethane Wheel
SKU
200-5000-APEX/FR
This 200 mm Apex heavy-duty leading brake castor is engineered for applications requiring exceptional... Read Full Description
In stock
£139.02
£115.85
- Price
- 1 + £139.02 £115.85
CAD Request
Frequently bought together
Alternative Products
Description
This 200 mm Apex heavy-duty leading brake castor is engineered for applications requiring exceptional load capacity, controlled straight-line travel and dependable braking performance. The castor combines a full swivel head with a leading brake mechanism, which automatically aligns the wheel in the direction of travel, helping to prevent unwanted sideways movement and improving overall handling of heavy loads.
With a robust 544 kg load capacity per castor, this model is ideal for demanding industrial environments. A ball journal bearing is fitted as standard, delivering smooth, low-resistance rolling while maintaining stability and reliability under high static and dynamic loads.
The castor is fitted with a 200 mm diameter ergonomic polyurethane wheel, finished in a high-visibility yellow. The 50 mm wide tread and 92 Shore A hardness are specifically designed to reduce rolling resistance and operator effort, while providing excellent durability and long service life. The wheel performs reliably within a –20 °C to +60 °C temperature range, making it suitable for a wide range of industrial and commercial applications.
A heavy-duty top plate fixing measuring 140 × 110 mm ensures secure mounting and effective load distribution. The plate features 105 × 80/75 mm hole centres with 10 mm bolt holes, allowing straightforward installation onto heavy-duty frames and equipment. This castor has a total height of 240 mm and a 180 mm swivel radius, providing stable manoeuvrability and controlled braking even when operating at maximum capacity.
Typical Applications
This 200 mm Apex leading brake castor is well suited to:
-
Heavy-duty industrial trolleys and transport equipment
-
Large mobile platforms requiring directional stability
-
Manufacturing and warehouse handling systems
-
Mobile machinery carrying high static and dynamic loads
-
Applications where reduced push force and improved control are critical
Why Choose Ross Handling
Ross Handling’s Apex heavy-duty castor range is designed to deliver strength, efficiency and long-term performance. This 200 mm leading brake castor with ergonomic polyurethane wheel provides an excellent solution where high load capacity, straight-line travel and operator comfort are essential.
Technical Details
 |
Top Plate Castors |
|---|---|
|
|
Ball Journal |
|
|
544 |
|
|
200-5000-APEX-FR.pdf |
|
|
50 |
|
|
-20 min to +60 max |
|
|
92 shore A |
|
|
1632 |
|
|
140 |
|
|
110 |
|
|
105 |
|
|
80/75 |
|
|
10 |
|
|
180 |
|
|
240 |
|
|
Yellow |
|
|
200 |
|
|
Ergonomic Polyurethane |
