Electro Conductive Castors 200mm Polyurethane Wheel and Brake
SKU
200-3360-HPP/SWB
This 200mm swivel braked electro-conductive castor is engineered for applications that require smooth... Read Full Description
In stock
£78.10
£65.08
- Price
- 1 + £78.10 £65.08
CAD Request
Frequently bought together
Alternative Products
Description
This 200mm swivel braked electro-conductive castor is engineered for applications that require smooth manoeuvrability, secure braking and electrostatic discharge (ESD) control. The electrically conductive rubber tread safely dissipates static electricity, helping protect sensitive equipment and components in electronics manufacturing, cleanrooms, laboratories and ESD-controlled industrial environments.
The swivel design provides easy directional movement, while the integrated brake locks both the wheel and swivel head to prevent unwanted rolling or swivelling once the equipment is positioned. Fitted with a polyurethane tyre bonded to a cast iron core, this castor delivers robust load support, excellent floor protection and reduced noise. A ball journal bearing ensures smooth and reliable rolling performance under load.
With a 400kg load capacity per castor (1200kg total for a set of four), this model is suitable for medium to heavy-duty trolleys, mobile workstations, industrial carts and equipment platforms that require both load support and ESD management. The 95 Shore A tread hardness balances wear resistance with smooth rolling action.
Key Features
-
Load Capacity: 400kg per castor / 1200kg per 4
-
Wheel Diameter: 200mm
-
Castor Type: Swivel with brake
-
Wheel Material: Electrically conductive polyurethane on cast iron
-
Bearing Type: Ball journal bearing
-
Tread Hardness: 95 Shore A
-
Temperature Range: -40°C to +80°C
-
Wheel Colour: Grey
-
Mounting: Top plate fixing
Applications
Suitable for:
-
ESD-sensitive environments
-
Electronics manufacturing and assembly
-
Cleanrooms and laboratories
-
Mobile workstations and equipment carts
-
Industrial platforms requiring secure braking
The electro-conductive tread helps reduce static build-up, protecting both sensitive electronics and personnel.
Why Choose Ross Handling
Ross Handling supplies castors selected for industrial reliability, effective ESD control and consistent performance. This electro-conductive swivel braked castor combines static dissipation, smooth manoeuvrability and secure braking, making it an excellent choice where both movement and electrostatic safety are essential in demanding environments.
Technical Details
 |
Top Plate Castors |
|---|---|
|
|
Ball Journal |
|
|
400 |
|
|
TSZ7 HPP 200/50 P3 BP 7012 |
|
|
200-3360-HPP-SWB.pdf |
|
|
50 |
|
|
-40 min to +80 max |
|
|
95 shore A |
|
|
1200 |
|
|
140 |
|
|
110 |
|
|
105 |
|
|
80/75 |
|
|
10 |
|
|
155 |
|
|
240 |
|
|
Grey |
|
|
200 |
|
|
Electrically Conductive Rubber |
