Electro Conductive Fixed Castors 80mm Polyurethane Wheel
SKU
80-3368-HPP
This 80mm fixed electro-conductive castor is engineered for static charge dissipation and stable... Read Full Description
In stock
£14.72
£12.27
- Price
- 1 + £14.72 £12.27
CAD Request
Frequently bought together
Alternative Products
Description
This 80mm fixed electro-conductive castor is engineered for static charge dissipation and stable straight-line movement in electrostatic-sensitive environments. The electrically conductive rubber tread safely directs static electricity away from the load, making this castor ideal for electronics manufacturing, cleanrooms, laboratories and controlled industrial areas where electrostatic discharge (ESD) control is essential.
Fitted with a polyurethane tyre bonded to a cast iron core, the wheel delivers strong load support, excellent wear resistance and floor protection while reducing noise. A ball journal bearing ensures smooth rolling performance under load, and the fixed (rigid) design provides reliable directional stability for equipment that does not require swivel motion.
With a 100kg load capacity per castor (300kg total for a set of four), this model is perfect for light-duty trolleys, mobile workstations, test rigs and equipment carts that require both load support and ESD management. The 95 Shore A tread hardness provides a balanced combination of durability and smooth rolling action.
Key Features
-
Load Capacity: 100kg per castor / 300kg per 4
-
Wheel Diameter: 80mm
-
Castor Type: Fixed
-
Wheel Material: Electrically conductive polyurethane on cast iron
-
Bearing Type: Ball journal bearing
-
Tread Hardness: 95 Shore A
-
Temperature Range: -40°C to +80°C
-
Wheel Colour: Grey
-
Mounting: Top plate fixing
Applications
Ideal for:
-
ESD-sensitive industrial environments
-
Electronics manufacturing and assembly
-
Cleanrooms and laboratories
-
Light-duty trolleys and equipment carts
-
Mobile workstations requiring straight-line stability
The electro-conductive tread helps manage static build-up, protecting both sensitive equipment and operators.
Why Choose Ross Handling
Ross Handling supplies castors selected for industrial reliability, effective ESD control and long-term performance. This electro-conductive fixed castor combines static dissipation with dependable construction and smooth, directional rolling, making it a strong choice where both load support and electrostatic safety are critical.
Technical Details
 |
Top Plate Castors |
|---|---|
|
|
Ball Journal |
|
|
100 |
|
|
TSZ7 HPP 080/30 P2 FA 7012 |
|
|
80-3368-HPP.pdf |
|
|
30 |
|
|
-40 min to +80 max |
|
|
95 shore A |
|
|
300 |
|
|
105 |
|
|
85 |
|
|
80 |
|
|
60 |
|
|
8 |
|
|
108 |
|
|
Grey |
|
|
80 |
|
|
Electrically Conductive Rubber |
