160mm Fixed Castor - Blue Non-Marking Rubber Wheel
SKU
160-3368-RNB
Fitted with a blue non-marking rubber wheel, this fixed castor is crafted for industrial use where directional stability is paramount. The wheel's elastic rubber tread, rated at A70 hardness, provides a balance between grip... Read Full Description
In Stock
£19.70
£16.42
- Price
- 1 + £19.70 £16.42
CAD Request
Frequently bought together
Alternative Products
Description
Fitted with a blue non-marking rubber wheel, this fixed castor is crafted for industrial use where directional stability is paramount. The wheel's elastic rubber tread, rated at A70 hardness, provides a balance between grip and resilience, while the roller bearings facilitate smooth movement. Constructed with a polypropylene core, the wheel is designed to handle loads up to 300kg, making it suitable for heavy-duty tasks. The castor is mounted using a top plate, ensuring a secure attachment to various equipment.
Key Features
- Tread Hardness: A70 – indicates the softness of the rubber, providing a balance between grip and resilience.
- Temperature Range: -20°C to +80°C – suitable for a range of environments.
- Load Capacity: 300kg
- Plate Length: 140mm – must match the mounting surface.
- Plate Width: 110mm – must match the mounting surface.
- Plate Hole Centres Length: 105mm – check against existing equipment.
- Plate Hole Centres Width: 80/75mm – check against existing equipment.
- Plate Hole Diameter: 10mm – must match the bolt size.
Applications
- Warehouse Trolleys: Used on trolleys for transporting heavy goods within warehouses.
- Industrial Carts: Fitted to carts for stable and controlled movement of materials.
- Manufacturing Equipment: Supports machinery and equipment in production lines.
- Storage Racks: Provides mobility to heavy storage units.
Why Choose Ross Handling
Ross Handling is a UK-based, family-run supplier of castors, wheels and handling components, established in 1977, with UK stock, fast delivery and an experienced team available to help you choose the right parts.
Technical Details
 |
Top Plate Castors |
|---|---|
|
|
3360 |
|
|
Roller |
|
|
300 |
|
|
160-3368-RNB_1.pdf |
|
|
40 |
|
|
-20 min to +80 max |
|
|
A70 |
|
|
140 |
|
|
110 |
|
|
105 |
|
|
80/75 |
|
|
10 |
|
|
200 |
|
|
Blue |
|
|
160 |
|
|
Rubber on Polypropylene |
